Gas Turbine Engine Combustion,
Emissions and Alternative Fuels
(la Combustion dans les turbomoteurs, les émissions et les
carburants de remplacement)
Papers presented at the Applied Vehicle Technology Pane1 (AVT} Symposium (organized by
the former AGARD Propulsion and Energetics Pane1 (PEP)), held in Lisbon, Portugal,
12-16 October 1998.
Published June 1999
