Fan Coil Range
HYDRONIC
TERMINALS
This document can be subjected to variations. Descriptions, performance data, images and diagrams are indicative only.
For further information contact Climaveneta Comunications/Marketing Department or visit www.climaveneta.com
Fan Coil Range
HYDRONIC
TERMINALS
i-LIFE2 |
202÷1002/204÷2004
pg. 4
Professional fan-coils with cabinet or
built-in version powered by EC Brushless
centrifugal fan 2 - 7,5 kW
HWD | 602÷1104
Ducted type terminal 4,8-15,1 kW
HWD HP | 0071÷0121
a-LIFE2 |
102÷1002/104÷1004
pg. 12
pg. 30
pg. 34
High head ducted type terminal
16,8-29,8 kW
Fan-coil for professional applications, with
cabinet or built-in version 1,5-7,5 kW
HRD | 021÷151
pg. 36
Heat recuperator unit 290-4000 m3/h
a-LIFE2 HP | 302÷1204
pg. 20
High head fan-coil for professional
application built-in version 2,88 - 8,60 kW
a-CHD | 606÷2209
pg. 38
Cassette type terminal 3,2-11,5 kW
i-LIFE Slim | 102÷502
pg. 24
Residential fan-coil with cabinet or
concealed version, with inverter motor
and tangential fan 0,84 - 3,86 kW
i-CHD | 706÷2209
MHD2 | 30÷60
CONTROLLERS
Hi-wall type terminal 2,15 - 4,63 kW
pg. 28
pg. 40
Cassette type terminal with continuous
variation of air flow and cooling power
4,56-10,6 kW
pg. 42
The wide range of available wall-mounted
and built-in controllers allows a user-friendly
and complete regulation of all the functions,
and an easy integration in home automation
and building management systems.
4
HYDRONIC TERMINALS
i-LIFE2
202÷1002 / 204÷1004
VERSION
DFIO built-in version, front air intake, horizontal installation
DFIV built-in version, front air intake, vertical installation
DLIO built-in version, low air intake, horizontal installation
DLIV built-in version, low air intake, vertical installation.
DFMO with cabinet, front air intake, horizontal installation
DFMV with cabinet, front air intake, vertical installation
DLMO with cabinet, low air intake, horizontal installation
DLMV with cabinet, low air intake, vertical installation
FEATURES
High efficiency EC motor. Modulating speed
centrifugal fan and air flow regulation.
Energy consumption reduced by more than 50%
Coils with aluminium fins and copper pipes.
Configurations for 2 and 4 pipe Systems.
Left-hand water connections, easy convertible into
right-hand, by simply turning the coil
Air filter on all models.
PROFESSIONAL FAN-COIL WITH CABINET OR
BUIT-IN VERSION, POWERED BY EC
BRUSHLESS CENTRIFUGAL FAN
2,00-7,50 kW
Automatically closing flap to cover and protect
electric controls from dripping water (in conformity
with directive 60335-2-40).
Elegant cover structure that integrates the use of
high quality plastic materials, with traditional
galvanized and precoated materials.
Structure in galvanised steel of high thickness for
maximum resistance to rust.
Auxiliary drain pan with thermal insulation for all
Horizontal versions, made of galvanized steel.
New i-LIFE2 fancoil is powered by a modulating speed centrifugal fan. This new concept of
fancoil operates with continuous air flow regulation assuring the best comfort and a concrete
energy savings. Thanks to the different versions, with cabinet or buit-in, low air intake or front
air intake, vertical or horizontal installation, it results very easy to find the perfect solution for
any requirement. A dedicated range of controllers allows a user friendly and complete
regulation of all the functions, and an easy integration in home automation, centralization and
Building Management Systems.
ACCESSORY
COMMANDS
EK PLUG-IN CONTROL /EKW WALL MOUNTED
CONTROL
User interface for selection of functioning mode
(OFF/summer/winter/AUTO), fan speed
(Max/Med/Min/AUTO), temperature set. Control of main
and additional coil valve unit (summer/winter - 2 and 4
pipes installation). Management of traditional ON/OFF valve
unit or modulating valve unit 0-10V or 3 points. Air and
water temperature probe. Multifunction digital input
configurable by user. Configuration dip switch. Modbus
protocol for installation in BMS (e.g. Idrorelax system by
Climaveneta). Installation and management of Master-Slave
system up to 8 LIFE fan coil units. Easy control installation
thanks to 2 wires connection.
INFRARED REMOTE CONTROL
Set-point regulation. Easy selection of the functioning mode
(cooling, heating, dehumidification, ventilation), and the fan
speed (Max, Med, Min, AUTO). User-sfriendly compact
remote control with fine aethetics. The receiver must be
Plastic drain pan for all Vertical versions.
connected to i-HB Power Board that must be mounted
on board of the unit.
IK CONTROL WITH LCD SCREEN
Interface with LCD screen with user-friendly icons.
Control kit for universal installation: wall-mounted as well
as plug-in. Selection of functioning mode
(Max/Med/Min/AUTO), temperature set. Control iK could
function manually or with weekly timer regulation
configurable by the customer. Control of main coil valve
unit (summer/winter - 2 pipes) and additional coil (winter
- 4 pipes). Management of traditional ON/OFF valve unit
or modulating valve unit 0-10V or 3 points (supply 230
VAC or 24V). Parameters configurable directly by user.
Modbus protocol for installation in Building Management
System (e.g. Idrorelax system by Climaveneta).
Installation and management of Master-Slave system up
to 8 LIFE fan coil units. Easy control installation thanks to
2 wires connection through HB power board.
Hot water coil kit
Kit RS485 - interface for Building Management System
Kit control board to manage 0-10V or 3 points
modulating valve unit
Main coil 2-way/3-way valve unit
Additional coil 2-way/3-way valve unit
Kit LIFE2 BOX
Kit Gateway interface for MyHome Bticino System
Air intake grille kit with version cover
Straight and angular (90°) plenum kits for air outlet
Plenum kit with round, straight or 90° air ducts.
Straight and angular (90°) plenum kits for air inlet
Heating element kit
Horizontal and vertical fan coil auxiliary tray
5
2P
4P
2 PIPES
4 PIPES
CONTROLLER
TECHNICAL DATA i-LIFE2
H
A
B
6
HYDRONIC TERMINALS
i-LIFE2
202÷1002
7
2P
4P
2 PIPES
4 PIPES
CONTROLLER
8
HYDRONIC TERMINALS
i-LIFE2
204÷1004
9
2P
4P
2 PIPES
4 PIPES
CONTROLLER
10
HYDRONIC TERMINALS
i-LIFE2
204÷1004
11
2P
4P
2 PIPES
4 PIPES
CONTROLLER
12
HYDRONIC TERMINALS
a-LIFE2
102÷1002 / 104÷1004
VERSION
DLMV with cabinet, low air intake, vertical installation
DLMO with cabinet, low air intake, horizontal installation
DFMV with cabinet, front air intake, vertical installation
DFMO with cabinet, front air intake, horizontal installation
DLIV built-in version, low air intake, vertical installation.
DLIO built-in version, low air intake, horizontal installation
DFIV built-in version, front air intake, vertical installation
DFIO built-in version, front air intake, horizontal installation
FEATURES
Centrifugal Fan with double air inlet, to ensure the
best performances with the best acoustic
emissions.
FAN-COIL FOR PROFESSIONAL APPLICATIONS,
WITH CABINET OR BUILT-IN VERSION
1,50-7,50 kW
Coils with aluminium fins and copper pipes.
Left-hand water connections, easy convertible into
right-hand, by simply turning the coil
6-speed autotransformer;
The new a-LIFE2 fancoil has been specifically developed to be adapted to every ambient
thanks to its modern and minimal design which is result of the full experience and
Climaveneta’s know-how on this range of products. Centrifugal fan with 6 speed via
auto-transformer. Thanks to the different versions, with cabinet or buit in, low air intake
or front air intake, vertical or horizontal installation, it results very easy to find the perfect
solution any time.
Automatically closing flap to cover and protect
electric controls from dripping water (in conformity
with directive 60335-2-40).
COMMANDS
PS PLUG-IN/PSW WALL MOUNTED
Fan speed slider, mode slider (OFF/summer/winter). ON/OFF
valve unit control (summer/winter for 2 pipes installation),
ON/OFF second valve unit control (winter for 4 pipes
installation). Remote water temperature probe.
input configurable by user. Configuration dip switch. Modbus
protocol for installation in BMS (e.g. Idrorelax system by
Climaveneta). Installation and management of Master-Slave
system up to 8 LIFE fan coil units. Easy control installation
thanks to 2 wires connection.
MT PLUG-IN/MTW WALL MOUNTED
Fan speed slider, mode slider (OFF/summer/winter). Thermostat
with set point regulation. ON/OFF valve unit control
(summer/winter for 2 pipes installation), ON/OFF second valve
unit control (winter for 4 pipes installation). Room temperature
probe. Remote water temperature probe.
AT PLUG-IN/ATW WALL MOUNTED
Mode button (OFF/summer/winter/AUTO), fan speed button
(Max/Med/Min/AUTO). Thermostat with set point regulation.
ON/OFF valve unit control (summer/winter for 2 and 4 pipes
installation). Control of traditional or PWM modulating valve
units. Room temperature probe and water temperature probe.
Digital input configurable as: window contact, economy, heating
or cooling remote changeover, periodic ventilation.
Configuration dip switch. TTL serial port with Modbus protocol
for installation in BMS.
Interface with LCD screen with user-friendly icons. Control kit
for universal installation: wall-mounted as well as plug-in.
Selection of functioning mode (OFF/summer/winter/AUTO),
fan speed (Max/Med/Min/AUTO), temperature set.
Control iK could function manually or with weekly timer
regulation configurable by the customer. Control of main coil
valve unit (summer/winter - 2 pipes) and additional coil
(winter - 4 pipes). Management of traditional ON/OFF valve
unit or modulating valve unit 0-10V or 3 points (supply 230
VAC or 24V). Parameters configurable directly by user.
Modbus protocol for installation in Building Management
System (e.g. Idrorelax system by Climaveneta).
Installation and management of Master-Slave system up to 8
LIFE fan coil units. Easy control installation thanks to 2 wires
connection through HB power board
EK PLUG-IN CONTROL /EKW WALL MOUNTED CONTROL
(OFF/summer/winter/AUTO), fan speed (Max/Med/Min/AUTO),
temperature set. Control of main and additional coil valve unit
(summer/winter - 2 and 4 pipes installation). Management of
traditional ON/OFF valve unit or modulating valve unit 0-10V or
3 points . Air and water temperature probe. Multifunction digital
speed (Max, Med, Min, AUTO). User-sfriendly compact
remote control with fine aethetics. The receiver must be
connected to i-HB Power Board that must be mounted on
board of the unit.
ACCESSORY
Hot water coil kit
Kit Bus Adapter for BMS
Kit RS485 - interface for Building Management System
Interface SPB Kit
Main and additional coil valve unit ON/OFF, PWM,
0-10V, 3 points 2-way or 3-way
Kit LIFE2 BOX
Air intake grille kit with version cover
Electric heaters
13
2P
4P
2 PIPES
4 PIPES
CONTROLLER
TECHNICAL DATA a-LIFE2
H
A
B
14
HYDRONIC TERMINALS
a-LIFE2
102÷1002
15
2P
4P
2 PIPES
4 PIPES
CONTROLLER
16
HYDRONIC TERMINALS
a-LIFE2
104÷1004
17
2P
4P
2 PIPES
4 PIPES
CONTROLLER
18
HYDRONIC TERMINALS
a-LIFE2
104÷1004
19
2P
4P
2 PIPES
4 PIPES
CONTROLLER
LIFE2 BOX
UNIT DESCRIPTION
LIFE2 BOX is a wall-mounted accessory that allows users to prepare the fan coil water and
electrical connections in advance. The fan coil is fitted inside the structure when the work
has been completed, thus simplifying the operations to be performed on site.
The kit consists of a galvanised sheet metal structure, front closing panel and frame with
manually adjustable flap. The kit is available in version painted RAL 9003 and also
NEUTRAL version (raw metal sheet).
LIFE2 BOX can house i-LIFE2 fan- coils, DLIV/DLIO version: low air inlet, vertical outlet.
It is available for sizes 100/200, 300/400, 500/600.
MODEL
A
LIFE2 BOX
LIFE2 BOX
LIFE2 BOX
102/104-202/204
302-304/402-404
502-504/602-604
20
HYDRONIC TERMINALS
a-LIFE2 HP
302÷1204
VERSION
DFIO
DFIV
DLIO
DLIV
built-in version, front air intake,
horizontal installation
built-in version, front air intake,
vertical installation
built-in version, low air intake,
horizontal installation
built-in version, low air intake,
vertical installation.
FEATURES
High pressure centrifugal fan unit for ducted
system.
Multi speed directly coupled electric motor.
Structure in hot galvanised steel for maximum
resistance to rust.
Left-hand water connections, easy convertible
into right-hand, by simply turning the coil.
HIGH HEAD FAN-COIL FOR PROFESSIONAL
APPLICATION BUILT-IN VERSION
2,88 - 8,60 kW
a-LIFE2 HP are professional high-head fan coils by Climaveneta.
The enhanced motor and the built-in version make these units ideal for ducted
systems in tertiary and commercial sectors.
B
COMMANDS
ATW WALL MOUNTED
ON/OFF valve unit control (summer/winter for 2 and 4
pipes installation). Control of traditional or PWM modulating
valve units. Room temperature probe and water
temperature probe. Digital input configurable as: window
contact, economy, heating or cooling remote changeover,
periodic ventilation. Configuration dip switch. TTL serial port
with Modbus protocol for installation in BMS.
MTW WALL MOUNTED
Fan speed slider, mode slider (OFF/summer/winter).
Thermostat with set point regulation. ON/OFF valve unit
control (summer/winter for 2 pipes installation), ON/OFF
second valve unit control (winter for 4 pipes installation).
Room temperature probe. Remote water temperature
probe.
PSW WALL MOUNTED
ON/OFF valve unit control (summer/winter for 2 pipes
installation), ON/OFF second valve unit control (winter for 4
pipes installation). Remote water temperature probe.
REMOTE CONTROL EKW
(Max/Med/Min/AUTO), temperature set. Control of main
and additional coil valve unit (summer/winter - 2 and 4
pipes installation). Management of traditional ON/OFF
valve unit or modulating valve unit 0-10V or 3 points.
Air and water temperature probe. Multifunction digital
input configurable by user. Configuration dip
switch.Modbus protocol for installation in BMS (e.g.
Idrorelax system by Climaveneta). Installation and
management of Master-Slave system up to 8 LIFE2 fan
coil units. Easy control installation thanks to 2 wires
connection.
Interface with LCD screen with user-friendly icons.
Control kit for universal installation: wall-mounted as well
as plug-in. Selection of functioning mode
(Max/Med/Min/AUTO), temperature set.
Control iK could function manually or with weekly timer
regulation configurable by the customer.
Control of main coil valve unit (summer/winter - 2 pipes)
and additional coil (winter - 4 pipes). Management of
traditional ON/OFF valve unit or modulating valve unit 010V or 3 points (supply 230 VAC or 24V). Parameters
configurable directly by user. Modbus protocol for
installation in Building Management System (e.g. Idrorelax
system by Climaveneta). Installation and management of
Master-Slave system up to 8 LIFE2 fan coil units. Easy
control installation thanks to 2 wires connection through
HB power board
speed (Max, Med, Min, AUTO).
User-sfriendly compact remote control with fine aethetics.
The receiver must be connected to i-HB Power Board that
must be mounted on board of the unit.
A
H
ACCESSORY
Hot water coil kit
Main and additional coil valve unit ON/OFF, PWM,
0-10 V, 3 points 2-way or 3-way
Kit RS485 - interface for Building Management
System
Interface SPB Kit
Heating element kit
Condensate drain pump
Hose kit
Straight and angular (90°) plenum kits for air inlet
21
2P
4P
2 PIPES
4 PIPES
CONTROLLER
DUCT
TECHNICAL DATA a-LIFE HP
a-LIFE2 HP / DFIV - DLIV
ELECTRICAL DATA
Power supply
Max absorbed power
2 PIPES SYSTEM CONFIGURATION
MAX SPEED
Air flow
Total capacity in cooling mode
Sensible capacity in cooling mode
Max water flow
Mad pressure drop
Total capacity in heating mode
Water flow in heating
Pressure drop in heating
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
0302
0402
0502
0602
0702
0802
0902
1002
1102
1202
V/ph/Hz 230/1/50
W
127
230/1/50
127
230/1/50
115
230/1/50
115
230/1/50
196
230/1/50
196
230/1/50
225
230/1/50
225
230/1/50
285
230/1/50
285
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
561
2,88
2,39
0,496
31,5
3,83
0,496
26,7
52
61
623
3,28
2,77
0,565
31,9
4,35
0,563
31,9
56
65
705
3,74
3,15
0,644
12,2
4,96
0,642
10,4
47
56
783
4,14
3,53
0,713
15,2
5,49
0,711
12,9
51
60
1004
4,62
3,91
0,795
19,5
6,13
0,794
16,8
52
61
1116
5,20
4,44
0,895
22,4
6,91
0,895
19,6
55
64
1390
6,20
5,14
1,067
33,5
8,22
1,065
29,4
54
63
1544
7,20
5,91
1,240
43,1
9,55
1,237
37,9
59
68
1740
8,05
6,99
1,386
14,2
10,7
1,383
14,1
57
66
1933
8,60
7,32
1,481
15,9
11,4
1,478
15,8
59
68
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
500
2,31
1,90
0,398
20,2
3,07
0,398
17,5
45
54
555
2,70
2,24
0,465
21,6
3,58
0,464
22,1
52
61
525
3,04
2,48
0,523
8,0
4,03
0,522
7,0
41
50
583
3,23
2,66
0,556
9,2
4,28
0,555
8,0
44
53
767
3,57
2,84
0,615
11,6
4,74
0,614
10,3
41
50
852
4,49
3,74
0,773
16,7
5,96
0,772
14,9
49
58
1078
5,70
4,67
0,981
28,3
7,57
0,980
25,2
51
60
1198
6,25
5,15
1,076
32,5
8,29
1,074
29,2
54
63
1547
7,50
6,46
1,291
12,3
9,95
1,289
12,2
55
64
1719
8,10
7,03
1,394
14,0
10,8
1,393
14,0
57
66
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
392
2,08
1,69
0,358
16,3
2,76
0,358
14,3
42
51
435
2,21
1,82
0,380
14,5
2,94
0,380
15,1
45
54
464
2,28
1,84
0,393
4,5
3,02
0,391
4,0
34
43
516
2,92
2,37
0,503
7,5
3,88
0,502
6,6
41
50
584
3,22
2,49
0,554
9,4
4,27
0,553
8,5
38
47
649
3,50
2,78
0,603
10,1
4,65
0,602
9,3
41
50
923
4,83
3,88
0,832
20,4
6,41
0,831
18,6
47
56
1026
5,40
4,42
0,930
24,3
7,16
0,927
22,3
51
60
1381
6,90
5,83
1,188
10,4
9,15
1,186
10,3
54
63
1534
7,40
6,25
1,274
11,7
9,82
1,272
11,7
54
63
(5)
(5)
(5)
(5)
mm
mm
mm
kg
650
215
450
14
650
215
450
15
850
215
450
20
850
215
450
21
1050
215
450
24
1050
215
450
25
1250
215
450
28
1250
215
450
29
1450
215
450
31
1450
215
450
34
0302
0402
0502
0602
0702
0802
0902
1002
1102
1202
V/ph/Hz 230/1/50
W
127
230/1/50
127
230/1/50
115
230/1/50
115
230/1/50
196
230/1/50
196
230/1/50
225
230/1/50
225
230/1/50
285
230/1/50
285
a-LIFE2 HP / DFIO - DLIO
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
561
2,88
2,39
0,496
31,5
3,83
0,496
26,7
52
61
623
3,28
2,77
0,565
31,9
4,35
0,563
31,9
56
65
705
3,74
3,15
0,644
12,2
4,96
0,642
10,4
47
56
783
4,14
3,53
0,713
15,2
5,49
0,711
12,9
51
60
1004
4,62
3,91
0,795
19,5
6,13
0,794
16,8
52
61
1116
5,20
4,44
0,895
22,4
6,91
0,895
19,6
55
64
1390
6,20
5,14
1,067
33,5
8,22
1,065
29,4
54
63
1544
7,20
5,91
1,240
43,1
9,55
1,237
37,9
59
68
1740
8,05
6,99
1,386
14,2
10,7
1,383
14,1
57
66
1933
8,60
7,32
1,481
15,9
11,4
1,478
15,8
59
68
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
500
2,31
1,90
0,398
20,2
3,07
0,398
17,5
45
54
555
2,70
2,24
0,465
21,6
3,58
0,464
22,1
52
61
525
3,04
2,48
0,523
8,0
4,03
0,522
7,0
41
50
583
3,23
2,66
0,556
9,2
4,28
0,555
8,0
44
53
767
3,57
2,84
0,615
11,6
4,74
0,614
10,3
41
50
852
4,49
3,74
0,773
16,7
5,96
0,772
14,9
49
58
1078
5,70
4,67
0,981
28,3
7,57
0,980
25,2
51
60
1198
6,25
5,15
1,076
32,5
8,29
1,074
29,2
54
63
1547
7,50
6,46
1,291
12,3
9,95
1,289
12,2
55
64
1719
8,10
7,03
1,394
14,0
10,8
1,393
14,0
57
66
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
392
2,08
1,69
0,358
16,3
2,76
0,358
14,3
42
51
435
2,21
1,82
0,380
14,5
2,94
0,380
15,1
45
54
464
2,28
1,84
0,393
4,5
3,02
0,391
4,0
34
43
516
2,92
2,37
0,503
7,5
3,88
0,502
6,6
41
50
584
3,22
2,49
0,554
9,4
4,27
0,553
8,5
38
47
649
3,50
2,78
0,603
10,1
4,65
0,602
9,3
41
50
923
4,83
3,88
0,832
20,4
6,41
0,831
18,6
47
56
1026
5,40
4,42
0,930
24,3
7,16
0,927
22,3
51
60
1381
6,90
5,83
1,188
10,4
9,15
1,186
10,3
54
63
1534
7,40
6,25
1,274
11,7
9,82
1,272
11,7
54
63
(5)
(5)
(5)
(5)
mm
mm
mm
kg
745
215
450
14
745
215
450
15
945
215
450
20
945
215
450
21
1145
215
450
24
1145
215
450
25
1345
215
450
28
1345
215
450
29
1545
215
450
31
1545
215
450
34
Notes:
1 Room temperature 27°C d.b./19°C w.b.; Chilled water (in/out) 7/12°C
2 Room temperature 20°C d.b.; Hot water (in/out) 50/* °C (with identical flow note1)
3 Sound pressure in semianechoic room at 1 (m.) from fan front and 1 (m.) from the ground
4 Sound power on the basis of measurements made in compliance with Eurovent 8/2.
5 Unit in standard configuration/execution, without optional accessories.
22
HYDRONIC TERMINALS
a-LIFE2 HP
302÷1204
a-LIFE2 HP / DFIV - DLIV
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
0304
0404
0504
0604
0704
0804
0904
1004
1104
1204
V/ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
W
127
127
115
115
196
196
225
225
285
285
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
561
2,88
2,39
0,496
31,5
2,34
0,205
13,6
52
61
623
3,28
2,77
0,565
31,9
2,66
0,233
17,3
56
65
705
3,74
3,15
0,644
12,2
3,29
0,288
26,3
47
56
783
4,14
3,53
0,713
15,2
3,64
0,319
31,7
51
60
1004
4,62
3,91
0,795
19,5
3,71
0,325
11,1
52
61
1116
5,20
4,44
0,895
22,4
4,18
0,366
13,9
55
64
1390
6,20
5,14
1,067
33,5
4,96
0,435
15,4
54
63
1544
7,20
5,91
1,240
43,1
5,76
0,505
20,4
59
68
1740
8,05
6,99
1,386
14,2
6,44
0,565
17,9
57
66
1933
8,60
7,32
1,481
15,9
6,88
0,603
20,1
59
68
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
500
2,31
1,90
0,398
20,2
1,88
0,165
9,0
45
54
555
2,70
2,24
0,465
21,6
2,19
0,192
12,0
52
61
525
3,04
2,48
0,523
8,0
2,67
0,234
17,8
41
50
583
3,23
2,66
0,556
9,2
2,84
0,249
20,0
44
53
767
3,57
2,84
0,615
11,6
2,87
0,252
6,8
41
50
852
4,49
3,74
0,773
16,7
3,61
0,316
10,5
49
58
1078
5,70
4,67
0,981
28,3
4,56
0,400
13,1
51
60
1198
6,25
5,15
1,076
32,5
5,00
0,438
15,6
54
63
1547
7,50
6,46
1,291
12,3
6,00
0,526
15,7
55
64
1719
8,10
7,03
1,394
14,0
6,48
0,568
18,1
57
66
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
392
2,08
1,69
0,358
16,3
1,69
0,148
7,3
42
51
435
2,21
1,82
0,380
14,5
1,79
0,157
8,2
45
54
464
2,28
1,84
0,393
4,5
2,00
0,175
10,4
34
43
516
2,92
2,37
0,503
7,5
2,75
0,225
16,6
41
50
584
3,22
2,49
0,554
9,4
2,59
0,227
5,6
38
47
649
3,50
2,78
0,603
10,1
2,81
0,246
6,5
41
50
923
4,83
3,88
0,832
20,4
3,86
0,338
9,6
47
56
1026
5,40
4,42
0,930
24,3
4,32
0,379
11,9
51
60
1381
6,90
5,83
1,188
10,4
5,52
0,484
13,5
54
63
1534
7,40
6,25
1,274
11,7
5,92
0,519
15,4
54
63
(5)
(5)
(5)
(5)
mm
mm
mm
kg
650
215
450
15
650
215
450
16
850
215
450
21
850
215
450
22
1050
215
450
25
1050
215
450
26
1250
215
450
29
1250
215
450
31
1450
215
450
32
1450
215
450
35
Notes:
1 Room temperature 27°C d.b./19°C w.b., Chilled water (in/out) 7/12°C
2 Room temperature 20°C d.b., hot water (in/out) 70/60°C
23
2P
4P
2 PIPES
4 PIPES
CONTROLLER
DUCT
a-LIFE2 HP / DFIO - DLIO
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
0304
0404
0504
0604
0704
0804
0904
1004
1104
1204
V/ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
W
127
127
115
115
196
196
225
225
285
285
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
561
2,88
2,39
0,496
31,5
2,34
0,205
13,6
52
61
623
3,28
2,77
0,565
31,9
2,66
0,233
17,3
56
65
705
3,74
3,15
0,644
12,2
3,29
0,288
26,3
47
56
783
4,14
3,53
0,713
15,2
3,64
0,319
31,7
51
60
1004
4,62
3,91
0,795
19,5
3,71
0,325
11,1
52
61
1116
5,20
4,44
0,895
22,4
4,18
0,366
13,9
55
64
1390
6,20
5,14
1,067
33,5
4,96
0,435
15,4
54
63
1544
7,20
5,91
1,240
43,1
5,76
0,505
20,4
59
68
1740
8,05
6,99
1,386
14,2
6,44
0,565
17,9
57
66
1933
8,60
7,32
1,481
15,9
6,88
0,603
20,1
59
68
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
500
2,31
1,90
0,398
20,2
1,88
0,165
9,0
45
54
555
2,70
2,24
0,465
21,6
2,19
0,192
12,0
52
61
525
3,04
2,48
0,523
8,0
2,67
0,234
17,8
41
50
583
3,23
2,66
0,556
9,2
2,84
0,249
20,0
44
53
767
3,57
2,84
0,615
11,6
2,87
0,252
6,8
41
50
852
4,49
3,74
0,773
16,7
3,61
0,316
10,5
49
58
1078
5,70
4,67
0,981
28,3
4,56
0,400
13,1
51
60
1198
6,25
5,15
1,076
32,5
5,00
0,438
15,6
54
63
1547
7,50
6,46
1,291
12,3
6,00
0,526
15,7
55
64
1719
8,10
7,03
1,394
14,0
6,48
0,568
18,1
57
66
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m3/h
kW
kW
m3/h
kPa
kW
m3/h
kPa
dB(A)
dB(A)
392
2,08
1,69
0,358
16,3
1,69
0,148
7,3
42
51
435
2,21
1,82
0,380
14,5
1,79
0,157
8,2
45
54
464
2,28
1,84
0,393
4,5
2,00
0,175
10,4
34
43
516
2,92
2,37
0,503
7,5
2,75
0,225
16,6
41
50
584
3,22
2,49
0,554
9,4
2,59
0,227
5,6
38
47
649
3,50
2,78
0,603
10,1
2,81
0,246
6,5
41
50
923
4,83
3,88
0,832
20,4
3,86
0,338
9,6
47
56
1026
5,40
4,42
0,930
24,3
4,32
0,379
11,9
51
60
1381
6,90
5,83
1,188
10,4
5,52
0,484
13,5
54
63
1534
7,40
6,25
1,274
11,7
5,92
0,519
15,4
54
63
(5)
(5)
(5)
(5)
mm
mm
mm
kg
745
215
450
15
745
215
450
16
945
215
450
21
945
215
450
22
1145
215
450
25
1145
215
450
27
1345
215
450
29
1345
215
450
31
1545
215
450
32
1545
215
450
36
Notes:
24
HYDRONIC TERMINALS
i-LIFE Slim
102÷502
VERSION
DLIU built-in version for universal installation.
DLMV with cabinet for vertical installation
DLMO with cabinet for horizontal installation
DLRV Radiant Version with cabinet for vertical
installation.
FEATURES
DC motor with inverter technology with continuous
speed regulation, to ensure the best performance
with a very low noise level.
Elegant design and reduced depth of only 13 cm,
for installation in a residential installation.
Tangential fan with asymetric blades that ensures
the continuous modulation of the air flow for a
better comfort and real energy savings.
Coil with large frontal area that allows to reach
high air flow with very low pressure drop.
Honeycomb polypropylene air filter which can be
regenerated by washing or blowing.
RESIDENTIAL FAN-COILS WITH CABINET OR
CONCEALED VERSION, WITH INVERTER MOTOR
E TANGENTIAL FAN.
0,84 - 3,86 kW
galvanized and precoated materials.
galvanized and epoxy powder coated materials.
Configuration for 2 pipes systems. (upon request
also for 4 pipes systems).
i-LIFE SLIM is the new fan coil Climaveneta, with inverter technology for heating, cooling and
dehumidifying. Its elegant design with only 13 cm depth makes i-LIFE Slim the perfect solution for
residential applications. The fan coil is also available with i-LIFE R-SLIM inverter version with radiant
panel. The brushless motor allows a perfect adaptation to thermal load, without any temperature
fluctuations. Tangential fans operate through continuous air flow modulation, with no speed steps or
relay switching as traditional fan coil units. High efficiency is guaranteed in any HVAC installation
setup, in combination with any low temperature heat generator.
H
COMMANDS
IKS
ON BOARD CONTROLLER
On-board control for unit with cabinet complete with touch
keypad with 8 touch key, LCD display with white light
symbols. Modulating fan speed with PID logic, temperature
regulation, winter/summer mode, automatic mode for the
speed regulation, night mode for a silent operation.
Minimum water probe and solenoid management.
REMOTE CONTROL IKSW
Remote controller for built-in and with cabinet units
complete with touch keypad with 8 touch keys, LCD
display with white light symbols.
Modulating fan speed with PID logic, temperature
regulation, winter/summer mode, automatic mode for the
speed regulation, night mode for a silent operation.
Minimum water probe and solenoid valve management.
A maximum of 31 fancoils can be connected to the iKSW
controller for open space rooms.
IHBS
ON BOARD SEMPLIFIED CONTROL
Simple on board controller for buit - in and with cabinet
units, to be coupled with remote controller iKSW.
A
iHBS controller has a touch button and a LED for the
visualization of the device’s operation. All the parameters
are set up from iKSW.
ATS
CONTROLLER WITH 4 SPEED REGULATION
Controller for units with cabinet. Interface with 4 keys for
the temperature selection, winter/summer mode, 4 speed
regulation, display for room temperature vizualization.
Minimum water temperature probe and solenoid valve
management.
HBS CONTROL
POWERBOARD CARD
Simple on board controler for built-in units or with cabinet
units, to be coupled with ATW Climaveneta remote control
or other remote controlers which manage the regulation of
the fixed fan speeds. HBS has a touch button and a LED
for the visualization of the device's operation. All the
parameters are set up from the remote controler.
B
ACCESSORY
Drain Pan for horizontal installation
Fitting for air intake in built-in installation
Telescopic air flow duct and 90° duct for false
ceiling and build in installation
Alluminium air flow vent for wall mounting
Alluminium Air intake grid
UVC air sterilisation device
Casing for build in version - i-LIFE Slim Box
Casing cover panel with frame and front panel grid
Eurokonus adapter
Pair of decorative and structural feet
25
TECHNICAL
NFT / U DATA i-LIFE Slim
2P
4P
2 PIPES
4 PIPES
CONTROLLER
26
HYDRONIC TERMINALS
i-LIFE Slim
102÷502
TECHNICAL
27
TECHNICAL
2P
4P
2 PIPES
4 PIPES
CONTROLLER
28
HYDRONIC TERMINALS
MHD2
30÷60
VERSION
-
Base Version
FEATURES
Fan coil in ABS with high mechanical
characteristics and resistance to ageing;
Adjustable air flow direction;
Arrangement for right-left condensate drain pipe;
Management of all functions by remote control
Removable panel;
HIGH - WALL TYPE TERMINAL
2,15 - 4,63 kW
MHD2 belongs to hi-wall fan-coils of Climaveneta. The compactness
of this model and its exclusive elegance soften the visual impact and
make it ideal for residential and small tertiary installations.
H
A
COMMANDS
Set-point regulation. Easy selection of the functioning
mode (cooling, heating, dehumidification, ventilation),
and the fan speed (Max, Med, Min, AUTO).
User-sfriendly compact remote control with fine
aethetics.
The receiver must be connected to i-HB Power Board
that must be mounted on board of the unit.
ACCESSORY
Frame kit
Solenoid valve 2 ways 1/2"
Solenoid valve kit 3 ways, 4 fits 1/2" with frame
B
29
2P
2 PIPES
WALL
TECHNICAL
NFT / U DATA MHD
MHD2
ELE CTRICAL DATA
Power suppl y
Max absorbed power
MAX SPEED
Air flow
Sensible capacit y in cooling mode
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEI GHT
A
B
H
Operating weight
V/ph/Hz
W
30
40
50
60
230/1/50
24
230/1/50
28
230/1/50
40
230/1/50
50
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m³/h
kW
kW
m³/h
kPa
kW
m³/h
kPa
dB(A)
dB(A)
436
2,15
1,82
0,37
8,9
2,48
0,37
9,0
34
45
632
2,67
2,13
0,46
15,0
3,20
0,46
14,9
41
52
780
4,00
3,02
0,69
38,5
4,20
0,69
38,5
44
55
920
4,63
3,91
0,80
49,9
5,07
0,79
49,7
49
60
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m³/h
kW
kW
m³/h
kPa
kW
m³/h
kPa
dB(A)
dB(A)
376
1,85
1,60
0,32
7,6
2,18
0,32
7,7
31
42
522
2,00
1,62
0,34
10,3
2,40
0,34
10,2
31
42
691
3,00
2,57
0,52
25,7
3,64
0,52
26,0
41
52
810
3,86
3,26
0,66
37,9
4,25
0,67
38,1
45
56
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m³/h
kW
kW
m³/h
kPa
kW
m³/h
kPa
dB(A)
dB(A)
334
1,65
1,42
0,28
6,8
1,91
0,28
6,8
27
38
403
1,78
1,45
0,31
8,8
2,13
0,30
8,7
28
39
570
2,67
2,13
0,46
21,9
3,21
0,46
21,8
37
48
697
3,36
2,83
0,58
30,7
3,67
0,58
31,1
42
53
(5)
(5)
(5)
(5)
mm
mm
mm
kg
845
180
270
10
845
180
270
10
920
200
298
13
920
200
298
13
Notes:
2 Room temperature 20°C d.b., hot water (in/out) 50/* °C (identical flow rate note 1)
CONTROLLER
30
HYDRONIC TERMINALS
HWD
602÷1104
VERSION
-
base version
FEATURES
Unit coils guarantee high efficiency thermal
exchange with low pressure drop. Finned unit coils
are made of copper tubes and high exchange
surface area aluminium fins. Coils are always
tested for leaks with dried air at 14 bar;
The electrical power and control switchboard
includes electronic air flow regulator and terminal
blocks for connection to power supply and remote
control;
Internal insulation in closed cell expanded
polyethylene with suitable thick to limit heat loss
and noise emission;
The fan units, with high available working
pressures, are fitted with balanced impellers to
guarantee maximum acoustic comfort.
DUCTED TYPE TERMINAL
Structure and base plate in hot-dip galvanised
4,8 - 15,1 kW
steel for maximum resistance to rust;
Extra modules available as accessories to the
standard unit;
HWD are Climaveneta ducted hydronic terminal units. The fan units at
available working pressures, through internal insulation, ensure excellent
acoustic comfort levels. The compactness and ease of installation make
HWD a suitable hydronic terminal unit for any type of setting.
Remote control to manage main unit functions to
provide a total enviroment comfort. Full Auto
function;
Arrangement for electronic control of two on/off
valve unit in the water circuit;
COMMANDS
NSW WALL MOUNTED
installation), ON/OFF second valve unit control (winter
for 4 pipes installation). Setting for minimum
temperature thermostat.
PSW WALL MOUNTED
for 4 pipes installation). Remote water temperature
probe.
MTW WALL MOUNTED
second valve unit control (winter for 4 pipes
installation). Room temperature probe. Remote water
temperature probe.
ATW WALL MOUNTED
Mode button (OFF/summer/winter/AUTO), fan speed
button (Max/Med/Min/AUTO). Thermostat with set point
regulation. ON/OFF valve unit control (summer/winter
for 2 and 4 pipes installation). Control of traditional or
PWM modulating valve units. Room temperature probe
and water temperature probe. Digital input configurable
as: window contact, economy, heating or cooling
remote changeover, periodic ventilation. Configuration
dip switch. TTL serial port with Modbus protocol for
installation in BMS.
PCE WALL-MOUNTED
Off/summer/winter/auto selector switch. Room
temperature control. Room temperature sensor.
Coil temperature sensor. Three speed air flow control +
Auto. Automatic summer/winter switching. Automatic
ON/OFF valve control.
H
A
ACCESSORY
Interface SPB Kit
Hot water coil kit
Heating element module
Delivery and intake plenum
Delivery plenum for round ducts
Two way intake plenum with air lock
B
31
2P
4P
2 PIPES
4 PIPES
CONTROLLER
TECHNICAL
DATA HWD
HWD
HWD
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
V/ph/Hz
W
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
kW
kW
kPa
kW
kPa
dB(A)
dB(A)
kW
kW
kPa
kW
kPa
dB(A)
dB(A)
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
kW
kW
kPa
dB(A)
dB(A)
(5)
(5)
(5)
(5)
mm
mm
mm
kg
kPa
kW
0602
0703
0803
0904
1003
1104
230-1-50
370
230-1-50
370
230-1-50
440
230-1-50
440
230-1-50
900
230-1-50
900
1300
4,80
3,00
0,826
12,0
6,61
0,826
9,0
1300
6,20
4,00
1,066
8,0
8,48
1,066
7,0
1600
8,00
5,20
1,376
14,0
11,8
1,376
14,0
1600
9,70
6,50
1,668
35,0
12,1
1,668
22,8
2200
11,5
7,40
1,978
24,0
16,7
1,978
21,0
2500
15,1
10,2
2,597
23,0
18,7
2,597
20,0
68
68
72
72
78
80
1171
4,50
2,80
0,774
11,0
6,19
0,774
8,0
1171
5,70
3,70
0,980
7,0
7,88
0,980
6,0
1357
7,20
4,60
1,238
11,0
9,34
1,238
12,0
1357
8,50
5,90
1,462
27,0
10,6
1,462
24,9
1985
10,7
6,90
1,840
22,0
13,7
1,840
19,0
2243
13,9
9,70
2,391
21,0
16,8
2,391
13,0
65
65
69
69
76
77
1021
4,10
2,60
0,705
9,0
5,65
0,705
8,0
1021
5,20
3,40
0,894
6,0
7,80
0,894
5,0
1057
6,00
3,90
1,032
9,0
7,75
1,032
7,0
1057
7,00
4,80
1,204
21,6
9,00
1,204
18,7
1585
9,10
6,00
1,565
17,0
13,5
1,565
9,0
1771
11,7
8,00
2,012
15,0
14,5
2,012
13,0
62
62
63
63
70
72
900
695
295
41
900
695
295
43
1050
695
295
50
1050
695
295
52
1250
750
315
63
1250
750
315
63
Notes:
1 Room temperature 27°C d.b./19°C w.b.; Chilled water (in/out) 7/12°C
2 Room temperature 20°C d.b.; Hot water (in/out) 50/* °C (with identical flow note1)
32
HYDRONIC TERMINALS
HWD
602÷1104
TECHNICAL
DATA HWD
HWD
HWD
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MED SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
MIN SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
V/ph/Hz
W
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
kW
kW
kPa
kW
kPa
dB(A)
dB(A)
kW
kW
kPa
kW
kPa
dB(A)
dB(A)
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
kW
kW
kPa
dB(A)
dB(A)
(5)
(5)
(5)
(5)
mm
mm
mm
kg
kPa
kW
602
703
803
904
1003
1104
230-1-50
370
230-1-50
370
230-1-50
440
230-1-50
440
230-1-50
900
230-1-50
900
1300
4,80
3,00
0,826
12,0
9,10
0,783
9,0
1300
6,20
4,00
1,066
8,0
9,10
0,783
9,0
1600
8,00
5,20
1,376
14,0
11,8
1,015
14,0
1600
9,70
6,50
1,668
35,5
11,8
1,015
34,1
2200
11,5
7,40
1,978
24,0
16,7
1,436
13,0
2500
15,1
10,2
2,597
23,0
18,0
1,548
15,0
68
68
72
72
78
80
1171
4,50
2,80
0,774
11,0
8,60
0,740
8,0
1171
5,70
3,70
0,980
7,0
8,60
0,740
8,0
1357
7,20
4,60
1,238
11,0
10,6
0,912
12,0
1357
8,50
5,90
1,462
27,3
10,6
0,912
29,2
1985
10,7
6,90
1,840
22,0
15,6
1,342
11,0
2243
13,9
9,70
2,391
21,0
16,8
1,445
13,0
65
65
69
69
76
77
1021
4,10
2,60
0,705
9,0
7,80
0,671
7,0
1021
5,20
3,40
0,894
6,0
7,80
0,671
7,0
1057
6,00
3,90
1,032
9,0
9,00
0,774
9,0
1057
7,00
4,80
1,204
21,8
9,00
0,774
21,9
1585
9,10
6,00
1,565
17,0
13,5
1,161
9,0
1771
11,7
8,00
2,012
15,0
14,5
1,247
10,0
62
62
63
63
70
72
900
695
295
41
900
695
295
43
1050
695
295
50
1050
695
295
52
1250
750
315
63
1250
750
315
63
Notes:
33
2P
4P
2 PIPES
4 PIPES
CONTROLLER
34
HYDRONIC TERMINALS
HWD HP
0071÷0121
VERSION
-
base version
FEATURES
Unit coils guarantee high efficiency thermal
exchange with low pressure drop. Finned unit coils
are made of copper tubes and high exchange
surface area aluminium fins. Coils are always
tested for leaks with dried air at 30 bar;
The electrical power and control switchboard
includes electronic air flow regulator and terminal
blocks for connection to power supply and remote
control;
Internal insulation in closed cell expanded
polyethylene with suitable thick to limit heat loss
and noise emission;
HIGH HEAD DUCTED TYPE TERMINAL
16,8 - 29,8 kW
Structure in galvanised steel of high thickness for
maximum resistance to rust;
Extra modules available as accessories to the
standard unit;
HWD HP belongs to ducted type fan-coils high head of Climaveneta.
The possibility of vertical or horizontal installation, airflow adjustment and attractive
external panelling guarantees an ease installation and make the unit adaptable to
any type of surroundings.
COMMANDS
NSW WALL MOUNTED
installation), ON/OFF second valve unit control (winter for
4 pipes installation). Setting for minimum temperature
thermostat.
PSW WALL MOUNTED
installation), ON/OFF second valve unit control (winter for
4 pipes installation). Remote water temperature probe.
MTW WALL MOUNTED
Room temperature probe. Remote water temperature
probe.
ATW WALL MOUNTED
regulation. ON/OFF valve unit control (summer/winter for
2 and 4 pipes installation). Control of traditional or PWM
modulating valve units. Room temperature probe and
water temperature probe. Digital input configurable as:
window contact, economy, heating or cooling remote
changeover, periodic ventilation.
Configuration dip switch. TTL serial port with Modbus
protocol for installation in BMS.
PCE WALL-MOUNTED
temperature control. Room temperature sensor. Coil
temperature sensor. Three speed air flow control + Auto.
Automatic summer/winter switching. Automatic ON/OFF
valve control.
H
A
ACCESSORY
Interface SPB Kit
Hot water coil kit
Delivery and intake plenum
Intake grill
Two way intake plenum with air lock
Ceiling brackets
Auxiliary condensate collecting tray
B
35
2P
4P
2 PIPES
4 PIPES
CONTROLLER
TECHNICAL
DATA HWD HP
HWD
HWD HP
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
V/ph/Hz
W
071
091
101
121
230V~50Hz
1
230V~50Hz
1
230V~50Hz
2
230V~50Hz
2
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m³/h
kW
kW
m³/h
kPa
kW
m³/h
kPa
dB(A)
dB(A)
3200
16,8
12,3
2,890
24,0
16,3
2,890
21,1
60
3200
20,1
14,4
3,440
22,0
19,6
3,440
19,3
60
4400
23,4
17,3
4,020
14,0
23,0
4,020
12,3
66
5000
29,8
21,7
5,100
11,9
29,8
5,100
10,5
69
(5)
(5)
(5)
(5)
mm
mm
mm
kg
1300
1119
510
121
1300
1119
510
124
1500
1349
625
145
1500
1349
625
149
0071
0091
0101
0121
230V~50Hz
1
230V~50Hz
1
230V~50Hz
2
230V~50Hz
2
Notes:
1 Room temperature 27°C d.b./19.5 °C w.b., Chilled water (in/out) 7/12°C
3 Sound pressure at 1 (m.) from fan front
HWD HP
ELECTRICAL DATA
Power supply
Max absorbed power
MAX SPEED
Air flow
Max water flow
Mad pressure drop
Noise Pressure
Noise Power
SIZE AND WEIGHT
A
B
H
Operating weight
V/ph/Hz
W
(1)
(1)
(1)
(1)
(2)
(2)
(2)
(3)
(4)
m³/h
kW
kW
m³/h
kPa
kW
m³/h
kPa
dB(A)
dB(A)
3200
16,8
12,3
2,890
24,0
25,0
2,200
13,0
60
3200
20,1
14,4
3,440
22,0
25,0
2,200
13,0
60
4400
23,4
17,3
4,020
14,0
36,0
3,200
19,0
66
5000
29,8
21,7
5,100
11,9
39,0
3,400
22,0
69
(5)
(5)
(5)
(5)
mm
mm
mm
kg
1300
1119
510
121
1300
1119
510
124
1500
1349
625
145
1500
1349
625
149
Notes:
1 Room temperature 27°C d.b./19.5 °C w.b., Chilled water (in/out) 7/12°C
36
HYDRONIC TERMINALS
HRD
021÷151
VERSION
-
base version
FEATURES
Removable aluzink plate side panels;
Panels insulated and soundproofed with
polyethylene/polyester with average thickness of
10 mm (mod. HRD 0021-0051) and 20 mm for the
other models;
High efficiency aluminium plate static type heat
recovery units, with airflow separated by special
seals;
HEAT RECUPERATOR UNIT
UE3 efficiency air filters, which may be easily
removed from any side of the unit (bottom, side,
top) for periodic cleaning;
290-4000 m /h
3
Fan casings on vibration-isolation mountings;
HRD heat recuperator units for residential and commercial application allow maximum room
comfort and energy saving. In modern systems is becoming necessary to create forced
ventilation, which involves air conditioned expelling; thereby consuming more energy and
consequenting increasing costs. HRD heat recuperators have obviated such as problems
using an aluminium static recovery unit that saves more than 50% energy, otherwise be lost
with expelled stale air. HRD can be integrated in traditional systems with fan coils, chillers
and radiators and may operate both in summer and winter. These units are recommended for
suspended ceiling installation and may be suitably ducted to allow the fresh air intake and
distribution.
Double inlet centrifugal fans for fresh air intake and
used air extraction, which may be removed from
any side of the unit for periodic maintenance;
Multi speed directly coupled electric motor;
A terminal block with a relay board is fitted on the
unit to aid electrical connections and fan control;
Stainless steel condensate collecting tray, with
condensate drain directed downwards;
COMMANDS
NSW WALL MOUNTED
for 4 pipes installation). Setting for minimum
temperature thermostat.
MTW WALL MOUNTED
second valve unit control (winter for 4 pipes
installation). Room temperature probe. Remote water
temperature probe.
ATW WALL MOUNTED
regulation. ON/OFF valve unit control (summer/winter
for 2 and 4 pipes installation). Control of traditional or
PWM modulating valve units. Room temperature probe
and water temperature probe. Digital input configurable
as: window contact, economy, heating or cooling
remote changeover, periodic ventilation. Configuration
dip switch. TTL serial port with Modbus protocol for
installation in BMS.
PCE WALL-MOUNTED
temperature control. Room temperature sensor. Coil
temperature sensor. Three speed air flow control +
Auto. Automatic summer/winter switching. Automatic
ON/OFF valve control.
H
A
ACCESSORY
Interface SPB Kit
Hot water coil kit
Cool water coil kit
Heating element kit
B
37
PLATE
CONTROLLER
TECHNICAL
DATA HRD
HWD
HRD
ELECTRICAL DATA
Power supply
Max absorbed power
PERFORMANCE
MAX SPEED
Air flow
Available static pressure
Noise Pressure
Efficency
Recovery heat exchanger capacity
Renewal air temperature
SIZE AND WEIGHT
A
B
H
Operating weight
021
031
051
071
091
101
121
V/ph/Hz 230V~50Hz 230V~50Hz 230V~50Hz 230V~50Hz 230V~50Hz 230V~50Hz 230V~50Hz
W
90
130
294
700
700
700
1100
151
400V-3N~50Hz
1500
(1)
(2)
(2)
(2)
m³/h
Pa
dB(A)
%
kW
°C
290
60
53
52,3
1,34
8,10
550
65
54
54,6
2,57
8,70
1000
90
54
53,4
4,60
8,30
1400
140
60
52,1
6,20
8,00
1900
120
58
51,8
8,40
7,90
2500
110
58
57,6
12,30
9,40
3200
170
61
56,0
15,30
9,00
4000
170
62
55,6
19,40
8,90
(3)
(3)
(3)
(3)
mm
mm
mm
kg
990
750
270
39
990
750
270
41
1150
860
385
68
1350
900
410
91
1450
900
470
99
1700
1230
490
140
1700
1230
530
155
1700
1230
630
179
Notes:
2 Size valued in the following Hypothesis: T inlet external air –5 °C; T ambient 20 °C ; nominal air capacity
38
HYDRONIC TERMINALS
a-CHD
0606 - 2209
VERSION
U-2T
electromechanical version for
2-pipe system
4-pipe system
U-4T
FEATURES
Frame in galvanised steel insulated with
self-extinguishing closed-cell polyethylene blanket
of suitable thickness, to limit heat loss and noise to
a minimum.
Airflow grille in ABS built in the cassette.
Supplied in 1 cartonbox 5-speed electric motor
inclusive of thermal switch.
Fan Low-rev radial-blade fan to maximise acoustic
comfort.
Coil with corrugated aluminium fins and copper
pipes, tested with dried air at 14 bar.
Switchboard with power and control terminal block
with screw terminals
Set-up for fresh air intake.
Set-up for duct air distribution.
Condensate auxiliary tray standard supplied;
CASSETTE TYPE TERMINAL
3,20-11,5 kW
New a-CHD cassette of Climaveneta, with 5 speeds AC motor, is available in two
version: for two pipe installation (unit with single coil) and for four pipe installation
(unit with double coil). Wide range of sizes and easy installation make them suitable
for all types of installations.
H
B
A
ACCESSORY
COMMANDS
MTW WALL MOUNTED
control (summer/winter for 2 pipes
for 4 pipes installation). Room temperature probe.
Remote water temperature probe.
Set-point regulation.Easy selection of the functioning
mode (cooling, heating, dehumidification, ventilation),
and the fan speed (Max, Med, Min, AUTO).
User-sfriendly compact remote control with fine
aethetics. The receiver must be connected to i-HB
Power Board that must be mounted on board of the
unit.
ATW WALL MOUNTED
button (Max/Med/Min/AUTO). Thermostat with set
point regulation. ON/OFF valve unit control
(summer/winter for 2 and 4 pipes installation).
Control of traditional or PWM modulating valve units.
Room temperature probe and water temperature
probe. Digital input configurable as: window contact,
economy, heating or cooling remote changeover,
periodic ventilation. Configuration dip switch.
TTL serial port with Modbus protocol for installation
in BMS.
Additional coil 2-way/3-way valve unit
Fresh Air renewal connection
Duct Connection Flange
39
TECHNICAL
DATA a-CHD
HWD
2P
4P
2 PIPES
4 PIPES
CONTROLLER
40
HYDRONIC TERMINALS
i-CHD
706-2209
VERSION
U-2T
2-pipe system
Version for 4 pipe installations,
can be realized with the cassette
i- CHD 2-pipe, via the valve
mounting 4FOR2.
U-4T
FEATURES
High efficiency EC motor. Modulating speed centrifugal
fan and air flow regulation.
Energy consumption reduced by more than 50%
Unit coils guarantee high efficiency thermal exchange
CASSETTE TYPE TERMINAL WITH
CONTINUOUS VARIATION OF
AIR FLOW AND COOLING POWER
4,56-10,6 kW
with low pressure drop. Finned unit coils are made of
copper tubes and high exchange surface area
aluminium fins. Coils are always tested for leaks with
dried air at 14 bar;
Frame in galvanised steel insulated with
self-extinguishing closed-cell polyethylene blanket
of suitable thickness, to limit heat loss and noise to
a minimum.
Airflow grille in ABS built in the cassette, supplied in 1
cartonbox.
Electrical power and control switchboard, complete
i-CHD is the new cassette of Climaveneta, with high efficency EC motor and
Centrifugal fans that operates through a continuous air flow modulation, with
low energy consumtion and perfect comfort. i-CHD is supplyed on 2 pipes
version. For the 4 Pipes installations we reccomend the 2 Pipes i-CHD
cassette with 4For2 kit valves.
with electronic air flow regulator and terminal board
for connection to network and available remote
controls;
Availability to have fresh air intake, distribute air flow
in four directions and also in different room place
thanks to air diffuser present on the unit;
Condensate auxiliary tray standard supplied;
COMMANDS
MTW WALL MOUNTED
Room temperature probe. Remote water temperature probe.
ATW WALL MOUNTED
ON/OFF valve unit control (summer/winter for 2 and 4 pipes
installation). Control of traditional or PWM modulating valve
units. Room temperature probe and water temperature probe.
Digital input configurable as: window contact, economy,
heating or cooling remote changeover, periodic ventilation.
Configuration dip switch. TTL serial port with Modbus protocol
for installation in BMS.
EK PLUG-IN CONTROL
EKW WALL MOUNTED CONTROL
(OFF/summer/winter/AUTO), fan speed (Max/Med/Min/AUTO),
temperature set. Control of main
and additional coil valve unit (summer/winter - 2 and 4 pipes
installation). Management of traditional ON/OFF valve unit or
modulating valve unit 0-10V or 3 points. Air and water
temperature probe. Multifunction digital input configurable by
user. Configuration dip switch. Modbus protocol for installation
in BMS (e.g. Idrorelax system by Climaveneta). Installation and
management of Master-Slave system up to 8 LIFE fan coil
units. Easy control installation thanks to 2 wires connection.
Interface with LCD screen with user-friendly icons. Control
kit for universal installation: wall-mounted as well as plugin. Selection of functioning mode
(Max/Med/Min/AUTO), temperature set. Control iK could
function manually or with weekly timer regulation
configurable by the customer. Control of main coil valve
unit (summer/winter - 2 pipes) and additional coil (winter 4 pipes). Management of traditional ON/OFF valve unit or
modulating valve unit 0-10V or 3 points (supply 230 VAC
or 24V). Parameters configurable directly by user. Modbus
protocol for installation in Building Management System
(e.g. Idrorelax system by Climaveneta). Installation and
management of Master-Slave system up to 8 LIFE fan coil
units. Easy control installation thanks to 2 wires connection
through HB power board.
Set-point regulation. Easy selection of the functioning
mode (cooling, heating, dehumidification, ventilation), and
the fan speed (Max, Med, Min, AUTO).
User-sfriendly compact remote control with fine aethetics.
The receiver must be connected to i-HB Power Board that
must be mounted on board of the unit.
H
B
A
ACCESSORY
Kit valves 4For2
Fresh Air renewal connection
Duct Connection Flange
i-HB Power box
Kit RS485 - interface for Building Management
System
41
TECHNICAL
DATA i-CHD
HWD
2P
4P
2 PIPES
4 PIPES
CONTROLLER
42
HYDRONIC TERMINALS
CONTROLLERS
THE WIDE RANGE OF AVAILABLE
WALL-MOUNTED AND BUILT-IN
CONTROLLERS, ALLOWS A USERFRIENDLY AND COMPLETE
REGULATION OF ALL THE FUNCTIONS,
AND AN EASY INTEGRATION WITH
HOME AUTOMATION, CENTRALIZATION,
BUILDING MANAGEMENT SYSTEMS.
Infrared Remote Control
Set-point regulation.
Easy selection of the functioning
mode (cooling, heating,
dehumidification, ventilation),
and the fan speed (Max, Med,
Min, AUTO). User-sfriendly
compact remote control with fine
aethetics. The receiver must be
connected to i-HB Power Board
that must be mounted on board
of the unit.
NS plug-in
NSW wall mounted
AT plug-in
ATW wall mounted
Fan speed slider, mode slider,
minimum temperature
thermostat and command of
on/off valves
Room thermostat, manualand automatic regulation of
fan, manualand automatic
mode change-over, roomand minimum temperature
probes and command of
on/off valves.
Multifunction digital contact.
Configuration dip switch.
PS plug-in
PSW wall mounted
MT plug-in
MTW wall mounted
Fan speed slider, mode
slider, minimum
temperature probe and
regulation of on/off valves
Room thermostat, fan
speed slider, mode slider,
room- and minimum
temperature probes and
regulation of on/off valves
EK plug-in
EKW wall mounted
iK universal
Room thermostat, manualand
automatic regulation of fan,
manual- and automatic
mode, change-over, roomand
minimum temperature
probes, regulation of electric
heater, valves (on/off or
modulating), serial
connection for mini-network
and integration into BMSor
Idrorelax systems
Notes
Refer to the dedicated product's pages for more information about compatibility between the controllers and the single fan coil.
The iK, EK, EKW controllers installed with a-LIFE and a-LIFE HP have to be combined with the 'HB LIFE' power board (cod. 7349051500).
Electronic control with LCD
display, room thermostat,
manual and automatic
regulation of fan, manual- and
automatic mode change-over,
room and minimum
temperature probes, regulation
of electric heater, valves (on/off
or modulating), 0-10 V output
for the regulation of the energysaving brushless fan motor,
serial connection for mininetwork and integration into
BMS or Idrorelax systems
43
MULTIPLE CONNECTION HYDRONIC TERMINALS
MODEL
a-LIFE2
i-LIFE2
a-LIFE2 HP
a-CHD
i-CHD
HWD
HWD HP
SIZE
10
20
30
40
50
60
70
80
90
100
20
40
60
80
100
30
40
50
60
70
80
90
100
110
120
606
706
1108
2209
706
1108
2209
602
703
803
904
1003
1104
71
91
101
121
NS-NSW (1)
1
1
1
1
0
0
0
0
0
0
PS-PSW (1)
8
8
6
6
6
6
3
3
3
3
5
5
5
5
2
2
2
3
1
1
0
0
0
0
0
0
0
0
0
0
MT-MTW (1)
8
8
6
6
6
6
3
3
3
3
5
5
5
5
2
2
2
3
1
1
20
20
20
20
20
20
20
0
0
0
0
0
0
0
0
0
0
AT-ATW (1)
3
3
2
2
2
2
1
1
1
1
2
2
2
2
1
1
1
1
0
0
15
15
15
15
15
15
15
-
SPB (2)
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
0
0
0
0
0
0
SPB (3)
9
9
9
5
4
4
3
2
2
2
3
3
2
2
2
2
2
2
2
2
1
1
1
1
0
0
0
0
0
0
Input *
0,2
0,2
0,3
0,3
0,3
0,3
0,6
0,6
0,73
0,73
0.5
0.5
0.6
0.6
0.6
0,42
0,42
0,49
0,49
0,85
0,85
1
1
1,3
1,3
0,22
0,37
0,64
1,35
0,34
0,76
1,74
1,3
1,3
1,55
1,55
3,5
3,5
2,9
2,9
7,9
9,5
For further information about connections to the units, please refer to the technical instructions of each controller.
Notes
(1) Maximum number of units of the same model that can be connected to a single controller
(2) Maximum number of units of different models and sizes that can be connected to a single controller (installing a SPB kit in each unit)
(3) Maximum number of units of the same size and model that can be connected to a controller (installing a single SPB kit)
(*) Current consumption of each unit in (A)
HYDRONIC TERMINALS_07-2014_ENG_00

a-LIFE2 - Climaveneta

Transcription

Documents pareils

Air cooled high temperature water chillers with screw
