7.92×24mm
•
204,345pages on
this wiki
Edit
• Classic editor
• History
Comments0
7.92×24mm
The basic 7.92×24mm N cartridges: 7.92×24 FMJ-RN, 7.92×24 FMJ-OGI, 7.92×24 C2F-, 7.92×24
BAP-67, 7.92×24 AP6-, 7.92×24 AP7.55Type
Place of origin
Designer
Designed
Manufacturer
Produced
Variants
Case type
Bullet diameter
Base diameter
Rim diameter
Rim thickness
Case length
Overall length
Case capacity
Personal defense weapon
Belgium
Production history
VBR-Belgium
2006–present
VBR-Belgium
2008–present
See Rounds
Specifications
Rimless, straight
7.92 mm (0.31 in)
9.14 mm (0.36 in)
8.62 mm (0.34 in)
1.27 mm (0.05 in)
24 mm (0.94 in)
32.40 mm (1.3 in)
0.926 cm3 (14 gr H2O)
Rifling twist
Primer type
Maximum pressure
254 mm (1 in 10 in)
Boxer Small pistol
320.01 MPa (46,000 psi)
Ballistic performance
Bullet weight/type
Velocity
Energy
503 m/s
71 gr (5 g) FMJ-RN FMJ
581 J (430 ft·lbf)
(1,700 ft/s)
320 m/s
110 gr (7 g) FMJ FMJ BT
365 J (270 ft·lbf)
(1,000 ft/s)
67 gr (4 g) BAP BAP
516 m/s
576 J (420 ft·lbf)
(1,700 ft/s)
85 gr (6 g) JHP JHP
---
---
Test barrel length: 200 mm (7.87 in)
The 7.92×24mm cartridge is a pistol cartridge designed in Belgium by Rik Van Bruaene of VBRBelgium.
The design objective was the development of a cartridge for use in Personal Defence Weapons
(PDW), and for use in pistols, submachine guns and carbines. The technical specifications of the
7.92×24mm round are much closer to the 9×19 mm NATO pistol round than that of the 4.6×30 mm
and 5.7×28 mm rounds more commonly used in PDWs. The 7.92×24mm is specially designed to
fulfill a multicaliber role in the existing 9×19mm and .45 Auto frame platforms.
Contents
[show]
Design objectives
Edit
The design objectives of the 7.92×24mm project were to create a new self-defence caliber with
great stopping power in a pistol and sufficient dimensions for use in a PDW or carbine style rifle.
The 7.92×24mm round exceeds the minimum FBI penetration requirements—12-inch penetration
when fired into ballistic gelatin.[1] The 7.92×24mm caliber is available on the civilian, law
enforcement and military markets.
The 7.92×24mm is shorter than the more ubiquitous 4.6×30mm and 5.7×28mm chamberings more
commonly used in PDWs, this to allow usage in compact and sub-compact weapons. In order to be
compatible with the 9×19mm and .45 Auto frame platforms, the 7.92×24mm caliber case has a
special selected length of 24mm and uses different bullet types for each frame platform to fit their
different lengths of 29.6mm and 32.4mm.
The 7.92×24mm S with short bullets and the 7.92×24mm N with long bullets
The round uses one standard case for both frame platforms and two series of bullets—the "S"
cartridge is used to fit in the 9×19mm frame platforms whilst the "N" cartridge is used in the .45
Auto frame platforms.
7.92×24mm case
Edit
<img
src="https://upload.wikimedia.org/wikipedia/commons/thumb/6/61/792hulzen2.jpg/180px792hulzen2.jpg" alt="792hulzen2" class="thumbimage " data-image-key="792hulzen2.jpg" dataimage-name="792hulzen2.jpg" width="180" height="216" >
.30 Carbine case and 7.92×24mm
To prevent ammunition supply problems caused by the launch of a new caliber, the 7.92×24mm
caliber uses a straight case, which is based on a shortened .30 Carbine case. These cases are widely
available all over the world, and can be easy modified for the 7.92×24mm projectile.
<img
src="https://upload.wikimedia.org/wikipedia/commons/7/7c/Hulsbodem792M.JPG"
alt="Hulsbodem792M" class="thumbimage " data-image-key="Hulsbodem792M.JPG" data-imagename="Hulsbodem792M.JPG" width="172" height="165" >
Head stamp of the modified 7.92×24mm case.
7.92×24mm N cartridge dimensions
Edit
The 7.92×24mm N cartridge is intent for the use in the .45 Auto frame platforms.
The 7.92×24mm has 0.926 ml (14.26 grains) H2O cartridge case capacity.
<img
src="https://upload.wikimedia.org/wikipedia/commons/thumb/5/55/7.92x24CIP.JPG/450px7.92x24CIP.JPG" alt="7.92x24CIP" class="" data-image-key="7.92x24CIP.JPG" data-imagename="7.92x24CIP.JPG" width="450" height="363" >
