REGIONAL MAP
ANAPA
KRYMSK
KRASNODAR & PASHKOVSKTY
NOVOROSSIYSK
GELENDZHIK
MAYKOP
MINERALNYE VODY
MOZDOK
NALCHIK
SOCHI-ADLER
GUDAUTA
SUKHUMI
SENAKI
KOPITNARI
KOBULETI
TBILSI
SOGANLUG
VAZIANI
BATUMI
TABLE OF FREQUENCIES
No
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
AIRFIELD
Anapa
Batumi
Gelendzhik
Gudauta
Kobuleti
Kopitnari
Krasnodar Center
Krasnodar-Pashkovskty
Krymsk
Maykop-Khanskaya
Mineralnye Vody
Mozdok
Nalchik
Novorossiysk
Senaki
Sochi-Adler
Soganlug
Sukhumi
Tbilsi
Vaziani
ICAO
URKA
UGSB
URKG
UG23
UG5X
UGKO
URKI
URKK
URKW
URKH
URMM
XRMF
URMN
URKN
UGST
URSS
UG29
UGSS
UGTB
UG29
REFERENCE
44o59’36”N,37o20’19”E
41o36’58”N,41o35’31”E
44o33’54”N,38o00’25”E
43o06’09”N,40o34’01”E
41o55’36”N,41o51’05”E
42o10’30”N,42o28’05”E
45o05’03”N,38o57’34”E
45o01’52”N,39o08’38”E
44o58’27”N,38o00’37”E
44o41’22”N,40o03’08”E
44o12’58”N,43o06’13”E
43o47’26”N,44o34’44”E
43o30’29”N,43o37’30”E
44o39’36”N,37o46’25”E
42o14’31”N,42o02’08”E
43o06’17”N,40o35’26”E
41o39’26”N,44o55’48”E
42o51’21”N,41o09’17”E
41o40’37”N,44o56’37”E
41o37’09”N,45o02’10”E
TOWER
121.0Mhz
131.0Mhz
126.0Mhz
130.0Mhz
133.0Mhz
134.0Mhz
122.0Mhz
128.0Mhz
124.0Mhz
125.0Mhz
135.0Mhz
137.0Mhz
136.0Mhz
123.0Mhz
132.0Mhz
127.0Mhz
139.0Mhz
129.0Mhz
138.0Mhz
140.0Mhz
ILS
TACAN
38Y,110.15Mhz
16X, BTM
40X, 110.30Mhz
34Y, 109.75Mhz
67X KBL
44X KTS
26X, 108.90Mhz
31X TSK
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
44o59’36”N
37o20’19”E
ELEV
148
AFD-227 [USAF]
OCT2010
TWR
121.0mHZ
ANAPA AIRPORT(URKA)
KRASNODAR REGION, RUSSIA
TOWER 121.0Mhz
ADF OTR 443.0Khz
ADF INR 215.0Khz
+6.0oE
N
NOTE:
READBACK OF ALL INSTRUCTIONS REQUIRED
D
ELEV
148
AIRCRAFT
SHELTERS
TWR
PARKING
AREA
AIRCRAFT
SHELTERS
AIRCRAFT
SHELTERS
PARKING
AREA
C
AIRCRAFT
SHELTERS
B
AIRCRAFT
SHELTERS
250 500
1000
2500
A
Scale 1:20000
ELEV
148
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
ANAPA AIRPORT (URKA)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
ILS
TACAN
REF
41o36’58”N
41o35’31”E
ELEV
36
AFD-227 [USAF]
OCT2010
TWR
131.0Mhz
BATUMI INTERNATIONAL AIRPORT (UGSB)
ADCHARA, GEORGIA
131.0Mhz
38Y
110.15Mhz
16X “BTM”
ELEV
36
+5.5oE
N
ILS LOC
HANGARS
D
TWR
C
TERMINAL
A
B
250 500
1000
ELEV
36
2500
Scale 1:10000
Designed by SHU77
ELEVATIONS AND DIMENSIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
ADCHARA, GEORGIA
AIRPORT DIAGRAM
BATUMI INTERNATIONAL AIRPORT (UGSB)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
44o33’54”N
38o00’25”E
ELEV
82
AFD-227 [USAF]
OCT2010
TWR
126.0Mhz
GELENDZHIK AIRPORT (URKG)
KRASNODAR REGION, RUSSIA
126.0Mhz
+5.9oE
ELEV
82
B
N
HANGARS
PARKING
AREA
PARKING
AREA
TWR
NOTE:
READBACK OF ALL INSTRUCTIONS REQUIRED
A
ELEV
82
250
1000
500
2500
Scale 1:8000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
GELENDZHIK AIRPORT (URKG)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
43o06’09”N
40o34’01”E
ELEV
82
AFD-227 [USAF]
OCT2010
TWR
130.0Mhz
GUDAUTA MILITARY AIRBASE (UG29)
APKHAZETI, RUSSIA
130.0Mhz
+5.9oE
ELEV
82
D
N
C
B
TWR
AIRCRAFT
SHELTERS
250 500
1000
2500
A
Scale 1:15000
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
ELEV
82
Designed by SHU77
APKHAZETI, RUSSIA
AIRPORT DIAGRAM
GUDAUTA MILITARY AIRBASE (UG29)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
ILS
TACAN
REF
41o55’36”N
41o51’05”E
ELEV
59
AFD-227 [USAF]
OCT2010
TWR
133.0Mhz
KOBULETI MILITARY AIRBASE (UG5X)
ADCHARA, GEORGIA
133.0Mhz
40X
110.30Mhz
67X KBL
+5.6oE
N
ELEV
59
ILS LOC
AIRCRAFT
SHELTERS
D
C
AIRCRAFT
SHELTERS
B
TWR
A
ELEV
59
250 500
1000
2500
Scale 1:10000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
ADCHARA, GEORGIA
AIRPORT DIAGRAM
KOBULETI MILITARY AIRBASE (UG5X)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
ILS
REF
42o10’30”N
42o28’05”E
AFD-227 [USAF]
OCT2010
ELEV
148
TWR
134.0Mhz
KOPITNARI INTERNATIONAL AIRPORT (UGKO)
KOPITNARI, GEORGIA
+5.7oE
134.0Mhz
34Y
109.75Mhz
44X KTS
TACAN
AIRCRAFT
SHELTERS
N
HANGARS
HANGARS
D
HANGARS
TWR
C
ELEV
148
HANGARS
B
A
ILS LOC
ELEV
148
AIRCRAFT
SHELTERS
250 500
1000
2500
Scale 1:15000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KOPITNARI, GEORGIA
AIRPORT DIAGRAM
KOPITNARI INTERNATIONAL AIRPORT (UGKO)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
45o05’03”N
38o57’34”E
ELEV
98
AFD-227 [USAF]
OCT2010
TWR
122.0Mhz
KRASNODAR CENTER MILITARY AIRBASE (URKI)
KRASNODAR REGION, RUSSIA
TOWER 122.0Mhz
ADF OTR 625.0Khz
ADF INR 303.0Khz
+6.2oE
N
WARNING
KRASNODAR CENTER IS IN
CLOSE PROXIMITY TO KRASNODAR
PASHKOVSKTY. ADDITIONAL CARE
SHOULD BE TAKEN IN THIS AREA
ELEV
98
ELEV
98
E
A
C
B
D
HANGARS
HANGARS
TWR
HANGARS
250 500
1000
2500
Scale 1:15000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
KRASNODAR CENTER MILITARY AIRBASE (URKI)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
45o01’52”N
39o08’38”E
ELEV
112
AFD-227 [USAF]
OCT2010
TWR
128.0Mhz
KRASNODAR-PASHKOVSKTY AIRPORT (URKK)
KRASNODAR REGION, RUSSIA
128.0Mhz
+6.2oE
N
WARNING
KRASNODAR PASHKOVSKTY IS IN
CLOSE PROXIMITY TO KRASNODAR CENTER .
ADDITIONAL CARE SHOULD BE TAKEN IN THIS AREA
ELEV
112
ELEV
112
TWR
F
I
E
H
TWR
D
J
C
HANGARS
B
G
A
ELEV
112
500
ELEV
112
1000
2500
Scale 1:20000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
KRASNODAR-PASHKOVSKTY AIRPORT(URKK)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
44o58’27”N
38o00’37”E
AFD-227 [USAF]
OCT2010
ELEV
66
TWR
124.0Mhz
KRYMSK MILITARY AIRBASE (URKW)
KRASNODAR REGION, RUSSIA
TOWER 124.0Mhz
ADF OTR 408.0Khz
ADF INR 830.0Khz
+6.0oE
ELEV
66
D
N
HANGARS
C
HANGARS
1000
250 500
2500
TWR
Scale 1:10000
HANGARS
B
ELEV
66
AIRCRAFT
SHELTERS
AIRCRAFT
SHELTERS
A
AIRCRAFT
SHELTERS
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION,, RUSSIA
AIRPORT DIAGRAM
KRYMSK MILITARY AIRBASE (URKW)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
44o41’22”N
40o03’08”E
AFD-227 [USAF]
OCT2010
ELEV
590
TWR
125.0Mhz
MAYKOP-KHANSKKAYA AIRBASE(URKH)
REPUBLIC OF ADYGEYA, RUSSIA
TOWER 125.0Mhz
ADF OTR 288.0Khz
ADF INR 591.0Khz
+6.2oE
ELEV
590
E
N
D
AIRCRAFT
SHELTERS
C
AIRCRAFT
SHELTERS
TWR
B
AIRCRAFT
SHELTERS
ELEV
590
A
250 500
1000
2500
Scale 1:15000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
REPUBLIC OF ADYGEYA, RUSSIA
AIRPORT DIAGRAM
MAYKOP-KHANSKAYA AIRBASE (URKH)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
44o12’58”N
43o06’13”E
ELEV
1050
AFD-227 [USAF]
OCT2010
TWR
135.0Mhz
MINERALNYE VODY AIRPORT (URMM)
STAVROPOL’SKIY KRAY, RUSSIA
TOWER 135.0Mhz
ADF OTR 583.0Khz
ADF INR 283.0Kh
+6.3oE
N
ELEV
1050
A
B
C
HANGARS
D
HANGARS
ELEV
1050
E
TWR
500
1000
2500
Scale 1:20000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
STAVROPOL’SKIY KRAY, RUSSIA
AIRPORT DIAGRAM
MINERALNYE VODY AIRPORT (URMM)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
43o47’26”N
44o34’44”E
ELEV
499
AFD-227 [USAF]
OCT2010
TWR
137.0Mhz
MOZDOK MILITARY AIRBASE (XRMF)
REPUBLIC OF NORTH OSSETIA-ALANIA, RUSSIA
137.0Mhz
+6.2oE
N
ELEV
499
ELEV
499
D
B
C
A
TWR
500
1000
2500
Scale 1:20000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
REPUBLIC OF NORTH OSSETIA-ALANIA, RUSSIA
AIRPORT DIAGRAM
MOZDOK MILITARY AIRBASE (XRMF)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
43o30’29”N
43o37’30”E
ELEV
1410.
AFD-227 [USAF]
OCT2010
TWR
136.0Mhz
NALCHIK AIRPORT (URMN)
REPUBLIC OF KABARDINO-BALKARIA, RUSSIA
+6.1oE
TOWER 136.0Mhz
ADF OTR 718.0Khz
ADF INR 315.0Kh
N
ELEV
1410
TWR
ELEV
1410
B
HANGARS
A
250 500
WARNING
DO NOT CONFUSE
THE ILLUMINATED HIGHWAY
WITH THE RUNWAY
1000
2500
Scale 1:10000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
REPUBLIC OF KABARDINO-BALKARIA, RUSSIA
AIRPORT DIAGRAM
NALCHIK AIRPORT (URMN)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
44o39’36”N
37o46’25”E
ELEV
131
AFD-227 [USAF]
OCT2010
TWR
123.0Mhz
NOVOROSSIYSK MILITARY AIRBASE (URKN)
KRASNODAR REGION, RUSSIA
123.0Mhz
+5.9oE
AIRCRAFT
SHELTERS
A
N
B
AIRCRAFT
SHELTERS
ELEV
131
TWR
AIRCRAFT
SHELTERS
C
TERMINAL
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
C
ELEV
131
250
500
1000
Scale 1:7500
2500
Designed by SHU77
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
NOVOROSSIYSK MILITARY AIRBASE (URKN)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
ILS
REF
ELEV
39
42o14’31”N
42o02’08”E
AFD-227 [USAF]
OCT2010
TWR
132.0Mhz
SENAKI MILITARY AIRBASE (UGST)
SAMEGRELO ZEMO-SVANETI, GEORGIA
132.0Mhz
26X
108.90Mhz
31X TSK
TACAN
+5.7oE
N
AIRCRAFT
SHELTERS
AIRCRAFT
SHELTERS
TWR
AIRCRAFT
SHELTERS
AIRCRAFT
SHELTERS
ILS LOC
A
B
C
D
E
27
ELEV
39
ELEV
39
250 500
1000
2500
Scale 1:10000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
SAMEGRELO ZEMO-SVANETI, GEORGIA
AIRPORT DIAGRAM
SENAKI MILITARY AIRBASE (UGST)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
REF
ELEV
98
43o06’17”N
40o35’26”E
AFD-227 [USAF]
OCT2010
TWR
127.0Mhz
SOCHI-ADLER INTERNATIONAL AIRPORT (URSS)
KRASNODAR REGION, RUSSIA
TOWER 127.0Mhz
ADF OTR 741.0Khz
ADF INR 365.0Khz
+5.7oE
N
ELEV
98
I
J
HANGARS
H
G
TWR
F
G
E
D
C
AIRCRAFT
SHELTERS
B
A
ELEV
98
ELEV
98
250 500
1000
2500
Scale 1:15000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
KRASNODAR REGION, RUSSIA
AIRPORT DIAGRAM
SOCHI-ADLER INTERNATIONAL AIRPORT (URSS)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
43o06’17”N
40o35’26”E
ELEV
1469
AFD-227 [USAF]
OCT2010
TWR
139.0Mhz
SOGANLUG AIRPORT (UG29)
TBILSI, GEORGIA
139.0Mhz
+5.6oE
ELEV
1469
A
N
B
C
TWR
D
NOTE:
READBACK OF ALL INSTRUCTIONS REQUIRED
E
ELEV
1469
250 500
1000
2500
Scale 1:10000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
TBILSI, GEORGIA
AIRPORT DIAGRAM
SOGANLUG AIRPORT (UG29)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
ELEV
39
42o51’21”N
41o09’17”E
AFD-227 [USAF]
OCT2010
TWR
129.0Mhz
SUKHUMI DRANDA AIRPORT (UGSS)
APKHAZETI, GEORGIA
129.0Mhz
+5.8oE
N
A
TWR
B
ELEV
39
C
D
D
E
ELEV
39
250 500
1000
2500
Scale 1:20000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
APKHAZETI, GEORGIA
AIRPORT DIAGRAM
SUKHUMI DRANDA AIRPORT (UGSS)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
41o40’37”N
44o56’37”E
ELEV
1528
AFD-227 [USAF]
OCT2010
TWR
138.0Mhz
TBILSI INTERNATIONAL AIRPORT (UGTB)
TBILSI, GEORGIA
138.0Mhz
+5.6oE
N
ELEV
1528
A
ELEV
1528
TWR
B
HANGARS
C
D
ELEV
1528
250 500
1000
ELEV
1528
2500
Scale 1:15000
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
TBILSI, GEORGIA
AIRPORT DIAGRAM
TBILSI INTERNATIONAL AIRPORT (UGTB)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AIRPORT
DIAGRAM
TOWER
REF
41o37’09”N
45o02’10”E
ELEV
1492
AFD-227 [USAF]
OCT2010
TWR
140.0Mhz
VAZIANI MILITARY AIRBASE (UG29)
TBILSI, GEORGIA
140.0Mhz
+5.6oE
N
A
ELEV
1492
AIRCRAFT
SHELTER
B
C
TWR
HANGARS
D
250 500
1000
2500
Scale 1:10000
E
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
ELEV
1492
Designed by SHU77
TBILSI, GEORGIA
AIRPORT DIAGRAM
VAZIANI MILITARY AIRBASE (UG29)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
NEVADA, AMERICA
AFD-227 [USAF]
OCT2010
UNITED STATES AIR FORCE
AIRPORT DIAGRAMS
NEVADA, AMERICA
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
RUSSIA AND CIS
AFD-227 [USAF]
OCT2010
REGIONAL MAP
GROOM AFB
NELLIS AFB
TABLE OF FREQUENCIES
No
1.
2.
AIRFIELD
Groom AFB
Nellis AFB
ICAO
KXTA
KLSV
REFERENCE
37o15’07”N,115o48’31”W
36o14’50”N,115o01’26”W
TOWER
127.5Mhz
127.5Mhz
ILS
TACAN
UNITED STATES AIR FORCE
NEVADA, AMERICA
AIRPORT
DIAGRAM
TOWER
REF
37o15’07”N
115o48’31”W
ELEV
4444
AFD-227 [USAF]
OCT2010
TWR
127.5Mhz
GROOM LAKE, AFB (KXTA)
NEVADA, AMERICA
127.5Mhz
+4.0oE
ELEV
4444
N
C
ELEV
4444
D
WARNING
LANDING AT GROOM LAKE AFB REQUIRES
SPECIAL PERMISSION. UNAUTHORISED
ENTRY INTO GROOM AIRSPACE MAY
RESULT IN THE USE OF LETHAL FORCE.
TWR
B
KXTA SHOULD NOT BE USED AS A
NAVIGATIONAL AID
HANGARS
500
1000
2500
A
ELEV
4444
ELEV
4444
Scale 1:30000
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
Designed by SHU77
NEVADA, AMERICA
AIRPORT DIAGRAM
GROOM LAKE, AFB (KXTA)
NOT FOR REAL NAVIGATION
UNITED STATES AIR FORCE
NEVADA, AMERICA
AIRPORT
DIAGRAM
TOWER
REF
36o14’50”N
115o01’26”W
ELEV
3690
AFD-227 [USAF]
OCT2010
TWR
127.5Mhz
NELLIS, AFB (KLSV)
NEVADA, AMERICA
+4.0oE
127.5Mhz
ELEV
3690
HANGARS
ELEV
3690
N
E
D
TWR
C
B
ARMING
AREA
RED FLAG
AREA
BOMBER
PADS
A
ELEV
3690
250 500
ELEV
3690
1000
Scale 1:15000
2500
Designed by SHU77
DIMENSIONS AND ELEVATIONS ARE IN FEET
BEARINGS IN MAGNETIC
UNLESS INDICATED OTHERWISE
NEVADA, AMERICA
AIRPORT DIAGRAM
NELLIS, AFB (KLSV)
NOT FOR REAL NAVIGATION
